MIL-DTL-2212K(SH)
TABLE VII. Basic dimensions of enclosures.
Across-the-line
Height
Width
Depth
Size
(inches)
(inches)
(inches)
0
30
30
10
1
30
30
10
2
30
30
10
3
30
30
10
4
30
30
10
5
40
40
15
6
50
40
25
7
50
40
25
Reduced-voltage
0
45
35
15
1
45
35
15
2
45
35
15
3
45
35
15
4
65
35
30
5
95
40
30
6
95
50
30
7
95
50
30
3.16.17 Safety. Electrical safety shall be in accordance with the requirements of MIL-E-917.
3.16.18 Painting. Parts not constructed of corrosion-resisting material, or having a corrosion-resistant
(see 6.8.21 and 6.8.72) treatment as specified in MIL-E-917, shall be painted as specified therein. Touching-up is
permitted for marks or scratches due to assembly, testing, or other handling.
3.16.19 Identification plates. Each controller shall have an identification plate containing the manufacturer's
name, catalog number, national stock number (NSN), if specified (see 6.2), voltage, frequency, and maximum
horsepower rating, and low noise (see 6.8.47), if applicable. Each associated switching device shall have
identification containing sufficient information to identify and reorder the item with information available in the
controller technical manual. Preferred location of the information is inside the enclosure of the controller and on the
outside of switch housings. Identification plates shall be not less than 0.02 inch in thickness, and shall be brass,
corrosion-resistant steel, or anodized aluminum marked by etching, engraving, stamping, or photo-processing.
Etching, engraving, or stamping shall be not less than 0.003 inch deep. Identification plates, when used for
associated devices, shall be securely fastened to the device. Where metal fasteners are not used, adhesive backed
metal (not less than 0.01 inch in thickness) on plastic film, Type G as specified in MIL-I-631 may be used. Items
that cannot be provided with a plate, such as tubular ceramic resistors, may be marked by stamping with a
permanent ink and covered by a protective coating that shall withstand the temperature characteristics the part will
exhibit. Controllers and switches shall be permanently and clearly marked with an identification plate showing the
function of each position subject to manual operation. Controllers having more than one source of power shall be
provided with an identification plate warning stating "WARNING all power sources shall be disconnected before
working on the controller." The word "WARNING" shall be established in accordance with MIL-E-917. The plate
shall be mounted on the front of the enclosure. When the controlled device is protected by special circuitry in the
controller, the identification of the associated sensor shall be clearly marked on an identification plate on the
controller. Laser marking of nameplates may be applied.
24
