MIL-DTL-29183/1B
Self-closing weatherproof
cover for circuit breaker
Carrying handle
access.
Inward sloping
connector
panel face
Low base mount
profile
Frame base
construction
A. Circular frame base
B. Trapezoid frame base
C. "A" frame base
D. Extended "A" frame base
NOTES:
1. These drawings are for reference only and illustrate some of the features required by the
specification of which it is a part. It is not intended that these drawings limit the design
except for the requirements specified herein.
2. Base mount type shall be similar to figure 2A, or 2B, or 2C, or 2D.
3. Carrying handle, inward sloping connector panel face(s), self-closing cover, frame
base construction, and low base mount profile are required.
FIGURE 2. Distribution panel design features.
