MIL-DTL-29183/1B
Hinged access panel: Not required (see MIL-DTL-29183).
Stability:
The vertical center of gravity shall be not more than 12.5 inches
(318 mm) above level ground. Additional stability requirements shall
apply in accordance with MIL-DTL-29183.
Lifting attachments: Crane lifting attachments are not required (see MIL-DTL-29183).
A carrying handle is required.
Electrical:
Input: The input to the distribution panel shall be 208Y/120 volt (V), 3-phase (ø),
4-pole (P), 5-wire (W), 60 Hertz (Hz).
Bus capacity: The bus bar capacity shall be 100 amperes (A).
Circuit breaker: The number of poles and current rating shall be as indicated in table I
herein and the voltage rating shall be sufficient for the intended
circuit.
PIN: The government part identification number (PIN) is as follows:
M 29183 / 1
Specification sheet number
General specification number
Prefix
TABLE I. Circuit characteristics.
Circuit breaker
Interface connector¹
Quantity
Circuit kind
Pole (P) - Ampere (A)
1
208Y/120V, 3-phase, 4P, 5W
None
NEMA L21-30P
1
208Y/120V, 3-phase, 4P, 5W
None
NEMA L21-30R
2
208V/120V, 1-phase, 3P, 4W
2P-20A
NEMA L14-20R
4
120V, 1-phase, 2P, 3W
1P-20A
NEMA L5-20R
1
Connector designations are National Electrical Manufacturers Association (NEMA) type numbers.
See MIL-DTL-29183.
2
