MIL-DTL-29183/6B
TABLE I. Circuit characteristics.
Quantit
Circuit breaker
Circuit kind
Interface connectorą
Pole (P) - Ampere (A)
y
1
208Y/120V, 3-phase, 4P, 5W
3P-350A
Terminals
4
208Y/120V, 3-phase, 4P, 5W
3P-100A
MS90555C44412Są
2
208Y/120V, 3-phase, 4P, 5W
3P-60A
MS90555C32412Są
2
208Y/120V, 3-phase, 4P, 5W
3P-30A
MS90555C28412Są
208Y/120V, 3-phase, 4P, 5W
2
3P-20A
MS17346R24N10Są
1
Connector designations are military type connectors conforming to MIL-C-22992. See MIL-DTL-29183.
TABLE II. Connector assignment and connector terminal wiring.
Ground,
Phase
Phase
Phase
green
C,
Neutral,
A,
B,
Circuit
Function
Interface connector
white
(bare)
red
blue
black
wire
wire
wire
wire
wire
Pressure type,
1
Input
T1
T2
T3
T0
G
terminal block,
minimum 600
1P
Paralleling kcmilą wire
P1
P2
P3
P0
G
size capacity
G1, G2
3, 4, 5, 6
Branch
MS90555C44412S˛
A
B
C
N
G3, G4
7, 8
Branch
MS90555C32412S˛
A
B
C
N
G
9, 10
Branch
MS90555C28412S˛
A
B
C
N
G
11, 12
Branch
MS17346R24N10˛
F
B
E
A
C
1
1000 (k) circular (c) mils (mil)
˛ Connector designations are military type connectors conforming to MIL-C-22992. See MIL-DTL-29183.
