MIL-DTL-29183/20A
TABLE II. Connector assignment and connector terminal wiring.
Ground,
Phase
Phase
Phase
Neutral,
green
B,
C,
A,
Circuit
Function
Interface connector
(bare)
blue
white
black
red
wire
wire
wire
wire
wire
1
Input
MS90558C32412P¹
A
B
C
N
G
2
Branch
MS90555C32412S¹
A
B
C
N
G
3, 4
Branch
L5-20R²
X³
W
G
5, 6
Branch
L5-20R²
X³
W
G
7
Branch
L5-15R²
X³
W
G
¹
Connector designations are military part numbers for military type connectors conforming to MIL-C-22992.
See MIL-DTL-29183.
² Connector designations conform to National Electrical Manufacturers Association (NEMA) standards.
³ Unmarked terminal.
TABLE III. Required accessory equipment.
Item
Quantity
Description
Part number
MIL-C-22992, class L, 60A wall mount,
1
1
MS90558C32412P¹
plug with coupling ring, connector
2
1
Protective cover (plug) for item 1
MS90564-3C¹
MIL-C-22992, class L, 60A, wall mount
MS90555C32412S¹
3
1
socket receptacle connector
4
2
Protective cover (cap) for item 3
MS90563-3C¹
NEMA L5-20R type connector, locking,
L5-20R²
5
4
socket receptacle
6
4
Protective receptacle cover for item 5
NEMA L5-15R type connector, locking,
7
1
L5-15R²
socket receptacle
8
1
Protective receptacle cover for item 7
¹ Designations are military part numbers for military type connectors conforming to MIL-C-22992.
See MIL-DTL-29183.
² Connector designations conform to National Electrical Manufacturers Association (NEMA) standards.
4
