MIL-DTL-29183/20A
Electrical:
Input: The input to the distribution panel shall be 208Y/120 volt (V), 3-phase (ø),
4-pole (P), 5-wire (W), 60 Hertz (Hz).
Bus capacity: The bus bar capacities shall be 60 amperes (A) (see figure 1).
Circuit breaker: The number of poles and current rating shall be as indicated in table I
herein and the voltage rating shall be sufficient for the intended
circuit.
PIN: The government part identification number (PIN) is as follows:
M 29183 / 20
Specification sheet number
General specification number
Prefix
TABLE I. Circuit characteristics.
Circuit breaker
Quantity
Circuit kind
Interface connector
Pole (P) - Ampere (A)
208Y/120V,
1
3P-60A
MS90558C32412P¹
3-phase, 5W
208Y/120V,
3P-60A
MS90555C32412S¹
1
3-phase, 5W
120V,
1P-20A
NEMA L5-20R²
4
1-phase, 3W
120V,
1
1P-15A
NEMA L5-15A²
1-phase, 3W
¹ Connector designations are military part numbers for military type connectors conforming to MIL-C-22992.
See MIL-DTL-29183.
² Connector designations conform to National Electrical Manufacturers Association (NEMA) standards.
2
