MIL-DTL-22438/2C
Inches
mm
Ltr
Min
Max
Min
Max
A
11.484
11.516
291.694
292.506
B
5.734
5.766
145.644
146.456
C
5.734
5.766
145.644
146.456
D
2.859
2.891
72.619
73.431
E
.390
.422
9.906
10.719
FIGURE 2. Wiring diagram and mounting dimensions - continued.
REQUIREMENTS:
Interface and physical dimensions: See figures 1 and 2.
Panel material: Steel.
Mounting: Designed for overhead mounting.
Electrical:
Bus connection terminal posts: Split-bolt type preferred. All posts including ground shall accept
maximum wire size AWG-3.
Interior wiring: Type D-10 in accordance with MIL-DTL-16878/3.
Retainer latch: MIL-DTL-2726/15, figure 1.
Intended use: Ship structure mounted, at test benches which require power at voltages or frequencies
other than ship service.
Part or Identifying Number (PIN): The PIN shall be M22438/2-001.
Referenced documents. In addition to MIL-DTL-22438, this document references the following:
The margins of this specification are marked with vertical lines to indicate where changes from the
previous issue were made. This was done as a convenience only and the Government assumes no
liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to
evaluate the requirements of this document based on the entire content irrespective of the marginal
notations and relationship to the last previous issue.
4
