MIL-DTL-29183/8B
Electrical:
Input: The input to the distribution panel shall be 480 volt (V) or 208 V, 3-phase (ø),
4-pole (P), 5-wire (W), 60 Hertz (Hz).
Bus capacity:
The bus bar capacities shall be 800 amperes (A) (see figure 1).
Circuit breaker: The number of poles and current rating shall be as indicated in table I
herein and the voltage rating shall be sufficient for the intended
circuit.
PIN: The government part identification number (PIN) is as follows:
M 29183 / 8
Specification sheet number
General specification number
Prefix
TABLE I. Circuit characteristics.
Circuit breaker
Interface connector
Quantity
Circuit kind
Pole (P) - Ampere (A)
480V or 208V,
3P-325A
4
Terminals
3-phase, 4P, 5W
(without trip)
480V or 208V,
4
3P-325A
Terminals
3-phase, 4P, 5W
480V or 208V,
3P-100A
Terminals
2
3-phase, 4P, 5W
480V or 208V,
3P-50A
Terminals
2
3-phase, 4P, 5W
2
