MIL-DTL-29183/16A
Bus capacity: The bus bar capacities shall be 200 amperes (A) (see figure 1).
Circuit breaker: The number of poles and current rating shall be as indicated in table I
herein and the voltage rating shall be sufficient for the intended circuit.
PIN: The government part identification number (PIN) is as follows:
M 29183 / 16A
Specification sheet number
General specification number
Prefix
TABLE I. Circuit characteristics.
Circuit breaker
Interface connector¹
Quantity
Circuit kind
Pole (P) - Ampere (A)
208Y/120V,
3P-200A
MS90558C52412P
1
3-phase, 5W
208Y/120V,
4
3P-60A
MS90555C32412S
3-phase, 5W
120V,
1P-20A
NEMA L5-20R²
12
1-phase, 3W
¹ Connector designations are military part numbers for military type connectors conforming to MIL-C-22992.
See MIL-DTL-29183.
2
