MIL-DTL-22438C
4.4 First article inspection. First article inspection shall subject one receptacle panel to the examination
and tests specified in table I in the order shown. The manufacturer shall provide verification to the
procuring activity that the first article inspection and tests have been performed on the receptacle panel
supplied to the requirements of this specification. One or more failures of first article examination or tests
shall be cause for rejection.
TABLE I. First article inspection.
Requirement
Test method
Inspection
paragraph
paragraph
Visual and mechanical examination
3.1, 3.3
Operation
Dielectric strength
Insulation resistance
Temperature rise
Vibration
Shock
4.5 Conformance inspection. This is inspection of product for delivery and shall consist of the
examination and tests specified in table II, in the order shown. One or more failures of conformance
inspection shall be cause for rejection.
TABLE II. Conformance inspection.
Requirement
Test method
Inspection
paragraph
paragraph
Visual and mechanical examination
3.1, 3.3
Operation
Dielectric strength
Insulation resistance
4.5.1 Inspection lot. An inspection lot shall consist of all panels covered by a single specification sheet
produced under essentially the same conditions, and offered for inspection at one time.
4.5.2 Sample size. The number of receptacle panels to be subjected to conformance inspection shall
be as shown in table III.
TABLE III. Conformance inspection, zero defect sampling plan.
Lot size
Sample size
1 -
8
100 percent
9 -
90
8
91 -
150
12
151 -
280
19
281 -
500
21
501 -
1200
27
1201 -
3200
35
3201 -
10,000
38
10001 -
35000
46
7
